Product Details
Place of Origin: Guangdong, China
Brand Name: GS
Model Number: NV20
Document: Product Brochure PDF
Payment & Shipping Terms
Price: Negotiable
Delivery Time: 6-8
Payment Terms: T/T
Supply Ability: 100
Unfold Size: |
1140*1300*575mm |
Folding Size: |
1010*610*575mm |
Diagonal Wheelbase: |
1480mm |
Weight: |
18KG |
Takeoff Weight: |
44.5KG |
Volume Of Medicine Cabinet: |
20L |
Spraying Flow: |
8L/Min |
Effective Spray Width: |
5-8M |
Flight Speed: |
5-10M/S |
Operation Power: |
58.8V(14S) |
Battery: |
14S 22000mah |
Operating Temperature: |
-10 ℃-- 40℃ |
Storage Mode: |
The Arm Folds Sideways |
Spraying System: |
Centrifugal Nozzle |
Flight Time: |
Empty Tank(20-25Min)Full Tank( 7-10Min ) |
Spreader Box Volume: |
33L(Limited 20kg ) |
Unfold Size: |
1140*1300*575mm |
Folding Size: |
1010*610*575mm |
Diagonal Wheelbase: |
1480mm |
Weight: |
18KG |
Takeoff Weight: |
44.5KG |
Volume Of Medicine Cabinet: |
20L |
Spraying Flow: |
8L/Min |
Effective Spray Width: |
5-8M |
Flight Speed: |
5-10M/S |
Operation Power: |
58.8V(14S) |
Battery: |
14S 22000mah |
Operating Temperature: |
-10 ℃-- 40℃ |
Storage Mode: |
The Arm Folds Sideways |
Spraying System: |
Centrifugal Nozzle |
Flight Time: |
Empty Tank(20-25Min)Full Tank( 7-10Min ) |
Spreader Box Volume: |
33L(Limited 20kg ) |
The NV20 features a 20-liter liquid tank, making it ideal for mid-to-large scale agricultural tasks such as spraying pesticides, herbicides, and fertilizers. Its high-capacity design reduces refill frequency and boosts operational efficiency in the field.
Equipped with a centrifugal nozzle system, the NV20 delivers a powerful and consistent spray with a flow rate of 8L/min and a spraying width of 5–8 meters. This ensures even distribution across crops and minimizes chemical waste.
With GPS positioning, radar obstacle avoidance, and remote control operation, the NV20 is built for precision and safety. It supports automated flight paths and intelligent return-to-home, making it easy to operate even in complex terrai
Thanks to its side-folding arm design, the NV20 is easy to transport and store. Its IP-rated waterproof and dustproof build allows for reliable performance in temperatures from –10°C to 40°C, making it suitable for tough agricultural environments.
Q: What is the capacity of the NV20’s liquid tank?
A: It comes with a 20L medicine tank, which supports continuous spraying with fewer interruptions for refilling.
Q: What is the maximum flight time?
A:The NV20 can fly for 7–10 minutes when fully loaded, and up to 25 minutes with an empty tank, depending on conditions.
Q: How wide is the spray coverage?
A: The effective spray width is between 5 to 8 meters, thanks to the powerful centrifugal nozzle system.
Q: Can the drone be used in harsh weather?
A: Yes. The NV20 is designed to work in temperatures ranging from –10°C to 40°C, and it is waterproof and dustproof for field durability.
Q: Is it easy to carry and deploy?
A: Absolutely. The drone’s foldable arms make it compact for transportation, and it can be deployed quickly with minimal setup time.
